Engine
Rover V8, 350 Chevrolet and various Diesel options are available.
Transmission
Manual or Automatic with permanent four wheel drive, two speed transfer gearbox. Centre manually operated diff lock or viscous coupling.
Suspension
Front live axle with coil springs, radius arms and panhard rod, double acting telescopic shock absorbers Rear live axle with coil springs.
Brakes
Servo assisted, All round discs, dual circuit 4 piston front calipers, 2 piston rear calipers
Tyres
33 x 12.5 x 15 All terrain or mud pattern
Wheels
8 x 15 or 10 x 15 Steel or Alloy
Donor vehicle
Range Rover or
Land Rover Discovery
Basic kit contents
Body shell and bonnet, gel coat coloured finish.
Roll cage assembly, Side frames, all necessary brackets, nuts and bolt pack, rear inner wheel arches, build manual.
Roll cage complete with rear seat belt mounts, 4 earth mounts for all electrics and floor supports on side frames.
Standard colours: Blue, Black, White, Red, Yellow, Green.
Weight
Width
Length
Height
Wheelbase
Track Width
Ground Clearance
All dimensions and measurements are for standard vehicle without wheel arch extensions and fitted with 33 x 12.5 x 15" tyres on 8" inch wheel rims.
1510kg
1810mm
3710mm
1910mm
2540mm
1590mm
280mm
